The compact vehicle computer
The MPCX28 is based on the Intel Pentium ZC with 2 independent video displays (DVI, VGA, LVDS). For mass storage, a robust hard drive (a flash disk is optional), a CompactFlash card and two USB memory stick brackets are built-in. Expansion options include GPS, GSM and WLAN. Absolutely noiseless operation is achieved through a robust aluminum profile which integrates passive and fanfree cooling.
| Type | MPCX48 |
|---|---|
| CPU | Intel® Processor® C140, 1GHz |
| Chipset | Intel® 855GME |
| Memory | 512MB (max. 1GB) |
| Ext. temp. hard drive1) | 0GB, 2.5" (max. 40GB) |
| Optical drive1) | Optional (814315) |
| Video controller | Intel® 855GME |
| Video memory | 64MB |
| 3D-Support | DirectX 9 |
| Video interface 1 | QXGA |
| Video interface 2 | DVI |
| Video interface 3 | - |
| Resolution | 2048 x 1536 (@ 75Hz) |
| Keyboard, mouse | USB |
| Serial interface COM1/CAN | RS232C |
| Serial interface COM2/CAN | RS232C |
| Serial interface COM3 | - |
| Serial interface COM4 | - |
| Parallel interface | LPT (opt. CAN) |
| USB V2.0 | 4x back, 2x front |
| TV input/Frame grabber | BT878A, SVideo, 3 channels |
| LAN Port A (with LAN boot) | 10/100BASE-T (RJ45) |
| LAN Port B | - |
| LAN Port C | - |
| Audio controller | AC97-2.3 |
| Line output | Stereo |
| Line input/mic. input | Stereo + headset |
| SPDif output | yes |
| Option 1 | WLAN MiniPCI |
| Option 2 | Dual-CAN |
| Option 3 | GSM |
| Option 4 | GPS |
| Digital input/output | Option: 3x isol. in/ 3x relay out |
| Remote power on/off | yes |
| Voltage input/power V1224 | 8V-30V DC / typ. 15W |
| Plug-in power supply | 110/220V AC Option |
| Expansion | MiniPCI, PC/104-Plus |
| Power save function | Suspend/Resume, SoftOff, Instant On |
| Conformity | CE, FCC, e1 |
| Protection class | IP52 |
| Size (W x L x H in mm) | 159 x 190 x 66 |
| Weight | 3 kg |
| Housing | Aluminium |
| Colour | anthracite/black anodized |
| Noise level | <20dB(A) |
| Operating temperature (with HD/CD) | -20°C to +50°C |
| Extended operating temperature (with CF) | -40°C to +70°C (CF, no CD/HD) |
| Vibration/shock incl. HD/CD/DVD | 1/10G |
| Vibration/shock (only CF) | 16/150G |
| MTBF (25°C) | 60'000h |
| For operating systems | WIN2000, WIN XP, LINUX |
